US TYPE High Tensile Forged Shackle G209

Ciri US TYPE High Tensile Forged Shackle G209US jenis
Bahanï¼š45 #
Baja palsu
Beban muktamadï¼šW.L.L * 4
Rawatan Permukaan ï¼šWarna sendiri, Zinc lipit, Hot dip dalvanized,
Zink penyaduran kromium trivalen, lapisan serbuk

Hantar Pertanyaan

Penerangan Produk

US TYPE High Tensile Forged Shackle G209Ciri

Jenis AS
Bahanï¼š45 #
Baja palsu
Beban muktamadï¼šW.L.L * 4
Rawatan Permukaan ï¼šWarna sendiri, Zinc lipit, Hot dip dalvanized,
Zink penyaduran kromium trivalen, lapisan serbuk

US TYPE High Tensile Forged Shackle G209 Spesifikasi

Saiz Nominal	Had beban kerja (tan)	Dimensinon (mm)											Berat masing-masing
Saiz Nominal	Had beban kerja (tan)	A	B	C	D	E	F	G	H	I	M	N	Berat masing-masing
3/16	1/3	9.65	6.35	22.4	4.85	15.2	14.2	24.9	37.3	4.06	28.4	4.85	0.03
1/4	1/2	11.9	7.85	28.7	6.35	19.8	15.5	32.5	46.7	4.85	35.1	6.35	0.05
5/16	3/4	135	9.65	31	7.85	21.3	19.1	37.3	53	5.6	42.2	7.85	0.09
3/8	1	16.8	11.2	36.6	9.65	26.2	23.1	45.2	63	6.35	51.5	9.65	0.14
7/16	1-1 / 2	19.1	12.7	42.9	11.2	29.5	26.9	51.5	74	7.85	60.5	11.2	0.17
1/2	2	20.6	16	47.8	12.7	33.3	30.2	58.5	83.5	9.65	68.5	12.7	0.33
5/8	3-1 / 4	26.9	19.1	60.5	16	42.9	38.1	74.5	106	11.2	85	17.5	0.62
3/4	4-3 / 4	31.8	22.4	71.5	19.1	51	46	89	126	12.7	101	20.6	1.07
7/8	6-1 / 2	36.6	25.4	84	22.4	58	53	102	148	12.7	114	24.6	1.64
1	8-1 / 2	42.9	28.7	95.5	25.4	68.5	60.5	119	167	14.2	129	26.9	2.28
1-1 / 8	9-1 / 2	46	31.8	108	29.5	74	68.5	131	190	16	142	31.8	3.36
1-1 / 4	12	51.5	35.1	119	32.8	92.5	76	146	210	17.5	156	35.1	4.31
1-3 / 8	13-1 / 2	57	38.1	133	36.1	92	84	162	233	19.1	174	38.1	6.14
1-1 / 2	17	60.5	41.4	146	39.1	98.5	92	175	254	20.6	187	41.1	7.8
1-3 / 4	25	73	51	178	46.7	127	106	225	313	25.4	231	57	12.6
2	35	82.5	57	197	53	146	122	253	348	31	263	61	20.4
2-1 / 2	55	105	70	267	69	184	145	327	453	35.1	330	79.5	98.9
